Product Summary
dormakaba SVP 6000 microswitch-monitored emergency-escape lock with automatic locking action and with divided follower, mechanical sequential control and signalling through integrated monitoring contact automatically lock the doors after each closing cycle for both convenience and security. The automatic deadbolt throw of 20 mm ensures that the door is always locked in accordance with property insurance requirements. Meanwhile, thanks to the added one-sided emergency escape function, the door can be opened at any time in the exit direction by simply operating the lever handle or it can be opened from the outside through a key or engageable external lever handle.
The lock is suitable for use in emergency exits and escape routes in compliance with EN 179 or on panic doors with a horizontal push bar in compliance with EN 1125.
- Certified in accordance with EN 179 and EN 1125
- Certified according to EN 12209 and 14846
- Automatic relocking action
- Mechanical process control
- Electrically activated external lever handle
- Versions: Operating current/closed-circuit current, 12 V/24 V
- With feedback contacts to signal door status
Description
Product Details
Convenient and secure
The SVP 6000 emergency-escape lock is particularly suitable for entrance or external doors that need to be permanently accessed from the inside but rendered accessible from the outside by authorised persons only. Thanks to the one-sided emergency escape function, the door can be readily opened in escape direction by simply operating the lever handle, while the automatic relocking mechanism ensures secure lock re-engagement once the door has closed.
Range of monitoring functions
The feedback contacts of the lock allow the latch, latch bolt, cylinder and lever handle all to be monitored. The signalling functions of the SVP 6000 are particularly suitable for monitoring and ensuring the convenient operation of doors in emergency exit and escape routes, but can also be used to trigger alarm systems or for remote monitoring.
Access control integration
Thanks to its external lever handle solenoid, the SVP 6000 offers a simple solution to satisfying property insurance locking requirements and also providing an effective access control system. The external lever handle can, for example, be activated by means of a floating signal triggered by a card reader.
Operational versatility
SVP locks are available in different models suitable for over-rebated or flush-closing timber doors and also narrow stile doors. They are flexible in terms of their installation position thanks to the non-handed (universal) trip latch. They have been approved as emergency exit locks for doors in escape routes, for emergency-escape locks with horizontal push bar and for use on fire and smoke doors.
